Machines Details
   Model:
QHS-1500/QHS-3000/QHS-4000/QHS-5000/QHS-6000
  Production capacity:
1000-2000/2500-3000/3500-4000/4500-5000/5500-6000
  Adjustable proportion of of syrup and water:
1:3-1:6
  CO2 content:
1.5-2.5/>2.5/>2.5/>3.5/>3.5
  Cooling water entry temperature/℃:
0-5
  Working pressure of carbonized and syrup tank/Mpa:
0.05-0.15
  Working pressure of storage tank/Mpa:
0.2-0.5
  Weight/KG:
500/1100/1300/1600/1800
1
Automatic with Alarm:The pressure in all tank and the liquid level of the machine are all controlled automatically with PLC.Once a error occurs,the alarm lamp will light and the alarm ring will sound and the mixer will stop automatically.
2
Easy operation and regulation:The operation of the mixer is especially convenient.Only turn around the buttons according to the pre-set program,the normal operation can be carried out.The production capacity,water-sugar proportion and gas content can be adjusted without exchanging and parts.
3
Easy operation and regulation:The operation of the mixer is especially convenient.Only turn around the buttons according to the pre-set program,the normal operation can be carried out.The production capacity,water-sugar proportion and gas content can be adjusted without exchanging and parts.
4
Enough gas content:The mixer adopts vacuum desoxidation technology at normal temperature.Its desoxidation ratio reaches above 90%.It has a baffle heat exchanger to cool the sugar-water mixture and carry out twice carbonating,So its carbon content is especially high.
STRINGENT PRODUCTION
Stringent production flow makes high-quality equipments efficiently.
1. Inspection
2.Polishing
3.Baking Varnish
4.Electroplating
5.Assembling
6.Delivery
