Robot Palletizer

Consulting Quotation

Machines Details

Technical Parameter

Model:

DRP-10/DRP-20/DRP-50

Palletizing Speed:

10；20；30~50Pcs/Min

Applicable:

Various Cartons, PE Film Shrink Wrapped Case, Bags etc

Power Rate:

About 10.0/12.0/16.0Kw

Voltage:

220/380V,3Phase, 50/60Hz

Air Consumption:

0.6;0.7;0.85M³/H

Air Pressure:

0.5-0.8Mpa

Working Db:

≤75/≤75/≤80Db

Machine Weight:

About 4800/5500/6000Kg

Dimensions:

At Least Need 4000*6000Mm Space (As Fact)

Function & Features

1

Robot Arm Palletizer Machine could divide into Standard Speed Type and High Speed Type. According to different speed and related conditions to choice different load value robot arm and grasp head.

2

DRP Series Robot Arm Palletizer Machine could independent finish products feeding,grouping arrange,empty pallet feeding, whole layer palletizing and full pallet feeding out works in continuously and automatically.
