X300 Top Pressure Fully Automatic Pallet Wrapping Machine

Consulting Quotation

Machines Details

Technical Parameter

Maximum Wrapping Speed:

15-25 Loads/Hour

Max Wrapping Height & Weight:

2200Mm / 2000Kg

Turntable Speed:

0-13Rpm(Adjustable)

Turntable Size:

1650Mm

Turntable Drive:

0.75Ph Chain Drive

Clamp And Cut Film:

Automatic

Machine Size:

L:2800Mm W:1650Mm H:3250Mm

Machine Weight:

800Kg

Standard Pre-Stretch:

300% Pre-Stretch

Film Capacity:

250Mm Diameter

Function & Features

1

High efficiency and low electricity-consumption, convenient in operation.

2

The wrapping type and times can be designed on customers’ requirements.

3

Photoelectric sensor test pallet height automatic

4

Auto reset of turntable

5

Pre-stretch ratio: 300%

6

Programmable control and frequency converter is available.

7

PLC control, manual optional. Wrap cycle (top, bottom, reinforcement) adjustment.
